Spurious
(non-harmonic)
DC to 1 MHz < -70 dBc
1 MHz to 10 MHz < -70 dBc + 6 dB/octave
Phase Noise (10kHz
offset)
–115 dBc/Hz (typical)
Square Wave Characteristic
Rise/Fall Time < 13 ns (10% to 90%) (typical, 1kHz, 1Vpp)
Overshoot < 2% (typical)
Duty Cycle 20% to 80% (to 8 MHz)
40% to 60% (to 16 MHz)
50% (>16 MHz)
Symmetry (below 50%
Duty Cycle)
1% of period+ 5ns
Jitter 1ns + 100ppm % of period
Ramp Wave Characteristics
Linearity < 0.1% of peak output (typical, 1kHz, 1Vpp, symmetry
100%)
Symmetry 0% to 100%
Pulse Wave Characteristics
Pulse Width 2000s max period;12ns min period; 1ns resolution
Variable Edge Time 5ns to 1ms
Overshoot < 2%
Jitter 1ns + 100ppm % of period
Arb Wave Characteristics
Frequency Range 1µHz to 12MHz (DG2041A)
1µHz to 8MHz (DG2021A)
Waveform Length 2 to 512 K points
Amplitude Accuracy 14 bits (including sign)
Sample Rate 100MSa/s
Minimum Edge Time 35ns (typical)
Jitter (RMS) 6 ns + 30ppm
Non-Volatile Storage 4 waveforms
