Output Characteristics
Amplitude
[1]
DG2041A:
20 mV
pp ~ 10 Vpp (50 Ω)
40 mV
pp ~ 20 Vpp (High Z)
DG2021A:
20 mV
pp ~ 5 Vpp (50 Ω)
40 mV
pp ~ 10 Vpp (High Z)
Amplitude Accuracy
(1 kHz sine wave)
± ( 1% of setting + 1 mVpp)
Amplitude Flatness (1
kHz sine wave)
< 100kHz 0.1 dB
100kHz to 5 MHz 0.15 dB
5 MHz to 40 MHz 0.3 dB
DC Offset
Range ( peak AC＋DC)
±5V (50Ω)
±10 V (High Z)
Offset Accuracy ± ( 2% of |the Offset Setting|+ 0.5% of the Amplitude +
2mV)
Waveform Output
Impedance 50 Ω (typical)
Isolation 42 Vpk max. to Earth
Protection Short-circuit protected; Overload disables the waveform
output automatically
AM Modulation
Carrier Waveforms Sine, Square, Ramp, Arb
Source Internal/ External
Modulating Waveforms Sine, Square, Ramp , Noise, Arb (2mHz to 20kHz)
Depth 0% ~ 120%
FM Modulation
Carrier Waveforms Sine, Square, Ramp, Arb
Source Internal/ External
Modulating Waveforms Sine, Square, Ramp, Noise, Arb (2mHz to 20kHz)
Frequency Deviation DC to 20MHz (DG2041A); 12.5MHz (DG2021A)
PM Modulation
Carrier Waveforms Sine, Square, Ramp, Arb
Source Internal/ External
Modulating Waveforms Sine, Square, Ramp, Noise, Arb (2mHz to 20kHz)
Phase Deviation 0 to 360°
FSK Modulation
