RIGOL
© 2006 RIGOL Technologies, Inc
User’s Guide for DG2000 Series
1-6
The Rear Panel at a Glance
Figure 1-5 The Rear Panel of DG2000 Series
Figure 1-6 The Rear Panel Operation Instruction of DG2000 Series
10MHz
Reference Input
Terminal
10MHz
Reference Output
Terminal
Modulation Input
T
erminal
External
T
ri
g/
FSk
/
Burst
USB Device Main Power
Switch
Power Socket
10/100
Ethernet
Digital
Output
RS-232
GPIB
(IEEE 488)
