where the file is saved depends on the File Path setting in St
orage menu. For details,
please refer to
To Save a File
.
Save Wave
• Click or tap Save Wave, then Operation is set to "Sav
e Wave".
• Select "Memory" or "Screen" under
Data Source as the source o
f the saved
waveform.
• Available options under
Format include "bin
" and "csv".
After setup, click or tap the
key at the upper-right corner of the front panel to
save the wav
eform based on the settings. The location where the file is saved
depends on the
File Path setting in Storage menu. For details, please refer to
To Save
a File
.
Save Setup
Click or tap
Save Setup, then Operation is set to "Sav
e Setup".
After setup, click or tap the
key at the upper-right corner of the front panel to
save the setup file suffix
ed with ".stp". The location where the file is saved depends on
the
File Path setting in St
orage menu. For details, please refer to
To Save a File
.
All Measurements
• Click or tap
All Measure, then Operation is set to "All Measure".
• In All Measure item, click or tap the drop-down button to select the channel
(CH1-CH4) to measure.
After setup, click or tap the key at the upper-right corner of the front panel to
perform the measurement on the specified channel.
Reset Statistics
• Click or tap Stat Reset, then Operation is set to "Stat Reset".
• Click or tap "Measure" or "Pass/Fail" under Stat Reset to reset all statistics of the
"Measure" or "Pass/Fail" function.
After setup, click or tap the key at the upper-right corner of the front panel.
This resets all statistics o
f the specified function in the
Result sidebar at the right side
o
f the screen and starts the measurements again.
Waveform Recording
Click or tap
Record, then Operation is set to "R
ecord".
System Utility Function Setting
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 User Guide
235
