Rigol DHO1202 User Manual

Menu
Attenuation
(display amplitude of the signal: actual
amplitude o
f the signal)
2X
5X
10X
20X
50X
100X
200X
500X
1000X
2000X
5000X
10000X
20000X
50000X
2:1
5:1
10:1
20:1
50:1
100:1
200:1
500:1
1000:1
2000:1
5000:1
10000:1
20000:1
50000:1
TIP
The oscilloscope auto-recognizes certain probes with a fixed attenuation ratio. After that, the
probe ratio will also be auto recognized to save you from configuring it manually.
Skew
The difference in the delays betw
een the probes, known as skew, can cause great
cable-delay errors in measurement results. To eliminate this problem, this series
oscilloscope provides the deskew function. Click or tap the
Skew input field to set the
delay time with the pop-up numeric k
eypad. You can also use the corresponding
numeric keypad to set the value. The value ranges from -100.00 ns to 100.00 ns, and
the default is 0.00 s.
Go Back to the Vertical Menu
In the
Probe setting menu, click or tap Vertical to go back to the Vertical menu.
Vertical System
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 User Guide
47
www.calcert.com sales@calcert.com1.888.610.7664
0
5
10
15
20
25
30

Rigol DHO1202 Specifications

General

Bandwidth	200 MHz
Channels	2
Vertical Resolution	12-bit
Vertical Sensitivity	1 mV/div to 10 V/div
FFT Points	1 Mpts
Operating Temperature	0°C to +50°C
Weight	2.5 kg
Input Impedance	1 MΩ ± 1%
Trigger Types	Edge, Pulse, Slope, Video, Pattern
Interface	USB Host, USB Device, LAN, HDMI
Memory Depth	50 Mpts
Display	10.1 inch LCD, capacitive touch screen
