Rigol DM3068 User Guide

RIGOL Chapter 6 Specifications
User’s Guide for DM3068
6-16
Measurement Rate
Measurement Rate
[1]
Function Setting Integration Time Readings/s 50Hz (60Hz)
DC Voltage
DC Current
2-wire Resistance
4-wire Resistance
0.006 PLC Integration Time 100 (100) us 10000 (10000)
0.02 PLC 400 (333) us 2500 (3000)
0.06 PLC 1.2 (1) ms 833 (1000)
0.2 PLC 4 (3.33) ms 250 (300)
1 PLC 20 (16.7) ms 50 (60)
2 PLC 40 (33.3) ms 25 (30)
10 PLC 200 (167) ms 5 (6)
100 PLC 2 (1.67) s 0.5 (0.6)
AC Voltage
AC Current
[2]
3Hz AC Filter 0.2
20 Hz 1.5
200 Hz 10
200 Hz 50
[3]
Frequency and
Period
[4]
1s Gate Time 1
0.1 s 10
0.01 s 80
0.001 s 500
Capacitance
[5]
25
[1]
Auto trigger, zero trigger delay, auto zero off, auto range off, math function off and external interface off.

Rigol DM3068 Specifications

General

Display Digits	6.5
Power Supply	100-240 V AC, 50/60 Hz
Weight	3.7 kg
DC Voltage Range	200 mV to 1000 V
DC Voltage Accuracy	±(0.0035% of reading + 0.0005% of range)
AC Voltage Range	200 mV to 750 V
AC Voltage Accuracy	0.06%
DC Current Range	200 µA to 10 A
DC Current Accuracy	0.05%
AC Current Range	200 μA ~ 10 A
Resistance Range	200 Ω ~ 100 MΩ
Resistance Accuracy	0.01%
Capacitance Accuracy	1%
Frequency Accuracy	0.01%
Temperature Range	-200°C
Connectivity	USB, LAN, GPIB
