User‟s Guide for DS1000 Series
Page 3 for Voltage Measurements
Figure 2-112 Table 2-75
Measure overshoot in percentage
of an edge
Measure preshoot in percentage of
an edge
Page 1 for Time Measurements
Figure 2-113 Table 2-76
Measure Period of a waveform
Measure Frequency of a waveform
Measure Rise Time of a rising edge
Measure Fall Time of a falling edge
Page 2 for Time Measurements
Figure 2-114 Table 2-77
Measure +Pulse Width of a pulse wave
Measure –Pulse Width of a pulse wave
Measure +Duty Cycle of a pulse wave
Measure –Duty Cycle of a pulse wave
