User‟s Guide for DS1000 Series
Key Points
Cursor Y: Cursors Y appear as horizontal lines on the display to measure vertical
parameters. Usually it is used to measure the Volts. When the source is set as
function, the units are assigned to the function.
Cursor X: Cursor X appears as vertical lines on the display to measure horizontal
parameters. Usually it indicates the time of trigger excursion. When the source is
set as FFT, X means frequency.
