Programming Introduction RIGOL
Programming Guide for DS1000CA Series
2-65
This command sets the mode of waveform points. <points_mode> can be:
NORMal, MAXimum or RAW.
Data points returned by :WAVeform:DATA? in different modes:
NORMal
RAW
MAX
MATH
600
600
In RUN state, MAX
is the same with
NORMal; in STOP
state, MAX is the
same with RAW.
FFT
500
500
CHx
600
5120
Half-Channel
CHx
600
10240
Returned Format:
The query returns NORMal, MAXimum or RAW.
Example:
:WAV:POIN:MODE NORM Set the mode as NORMal.
:WAV:POIN:MODE? Return NORMal.
