Plug-in Module Overview
M300 provides 10 kinds of modules including the DMM module, 32-channel
multiplexer, 64-channel multiplexer, multi-function module, etc. This section
introduces the functions and characteristics of each module.
Outside View drawing of the module
Figure 6 Outside View Drawing of the Module
Golden Circuit board Edge: each on the
top and bottom for sliding into the slot
Interface 1: connect the signal under test via the
terminal block (the DMM module does not have this
interface)
Interface 2: connect
with the main frame
