RIGOL
M300 Quick Guide
24
2. Connect the cables for connecting the signal under test according to the labels
on the circuit board of the terminal block (for the connecting method, refer to
Table 1). Pass the binding wires through the two groups of holes as pointed out
by the arrows in the figure below to fix the cable connected. Pay attention to the
channel or terminal connected to the cable to ensure that the signal connected
is correct.
3. Connect the terminal block to the module via interface 1 (the interface definition
is in Figure 6) on the module and screw down the two screw rods onto the nuts
on the module.
