Chapter 15 Accessibility Setting RIGOL
MSO1000Z/DS1000Z User’s Guide 15-5
DHCP and Auto IP will be “Off” and the oscilloscope will load the preset subnet
mask automatically at the next power-on.
Set the Gate
You can set this paramter in Auto IP and Static IP mode.
The format of the gate is nnn.nnn.nnn.nnn; wherein, the range of the first nnn is
from 0 to 223 (except 127) and the ranges of the other three nnn are from 0 to 255.
You are recommended to ask your network administrator for a gate address
available.
Press Gate and use to input the desired gate address. This setting will be saved
in the non-volatile memory and if “Power-off Recall” is set to “Last”, DHCP and
Auto IP will be “Off” and the oscilloscope will load the preset gate address
automatically at the next power-on.
Set the Domain Name Server
You can set this paramter in Auto IP and Static IP mode.
The address format of the domain name server is nnn.nnn.nnn.nnn; wherein, the
range of the first nnn is from 0 to 223 (except 127) and the ranges of the other three
nnn are from 0 to 255. You are recommended to ask your network administrator for
an address available.
press DNS and use to input the desired address. Generally, users do not need to
set the DNS, therefore this parameter setting can be ignored.
When the three IP configuration types are all turned on, the priority of the
parameter configuration from high to low is “DHCP”, “Auto IP” and “Static IP”.
The three IP configuration types cannot be all turned off at the same time.
Apply the Network Parameter Setting
Press Apply to validate the current network parameter setting.
Initialize the Network Parameters
Press Initialize to return the network parameters to the default state.
