RIGOL Chapter 15 Accessibility Setting
15-6 MSO1000Z/DS1000Z User’s Guide
MAC Address
For each oscilloscope, the MAC address is unique. When attributing IP address for
the oscilloscope, the MAC address is usually used to identify the instrument.
VISA Address
Display the VISA address currently used by the oscilloscope.
USB Device
Press Utility IO Setting USB Device to select the device type (“Computer”
or “PicBridge”) connected to the USB device interface and the default is “Computer”.
When “Computer” is selected, the oscilloscope can communicate with the PC. When
“PictBridge” is selected, you can print the content displayed on the screen via a
PicBridge printer.
GPIB Address
When using the GPIB mode to control the oscilloscope, you need to extend a GPIB
interface for the oscilloscope using the USB-GPIB interface converter (need to be
ordered separately).
To set the GPIB address of this interface, press Utility IO Setting GPIB and
use to input the desired address. The default is 1 and the range is from 1 to 30.
