Chapter 15 Accessibility Setting RIGOL
MSO1000Z/DS1000Z User’s Guide 15-9
MSO1000Z/DS1000Z digital oscilloscope supports the PictBridge printer function.
Printers that support PictBridge can be connect directly via the USB Device connector
at the rear panel of the oscilloscope. You can set the printer parameters using the
oscilloscope to output the corresponding picture.
After connecting the printer, you need to first set the USB device type of the
oscilloscope. Press Utility IO Setting USB Device to select “PictBridge”.
Then, press Utility Print Set to set the print parameters.
1. Print
After setting the print parameters, press this key or press
at the front
panel to execute the print operation.
2. Continue
When the print is paused, press this key to resume the unfinished print.
Note: This key is only available after the print is paused.
3. Abort
Pressing this key can stop the current print via the oscilloscope.
Note: This key is only available during the print process.
4. Status
Press this key and pop-up message box will be displayed on the screen showing
the current print status.
5. Print Range
Press this key to set the print range to “Screen” or “Wave” and the default is
“Screen”.
Screen: print the whole screen image.
Wave: only print the waveform area.
6. Palette
Press this key to set the print color to “Gray Scale” or “Color” and the default is
“Color”.
7. Paper Size
Press this key to open the size list and rotate the multifunction knob
to
select the desired paper size. You can also press this key continuously to switch
among the options. The sizes include “Default”, “A2”, “A3”, “A4”, “A5”, “A6” or
“B5”.
Note: The paper sizes available are related to the property of the printer
connected. Sizes not supported by the printer cannot be selected.
8. File Type
Press this key to open the file type list and rotate the multifunction knob
to
