Rigol MSO1000Z series User Manual

RIGOL Chapter 18 Specifications
18-2 MSO1000Z/DS1000Z User’s Guide
Horizontal
Timebase Scale
5 ns/div to 50 s/div
Max Record
Length
24 Mpts (optional)
Timebase
Accuracy
[1]
≤±25 ppm
Clock Drift
≤±5 ppm/year
Max Delay
Range
Negative delay: ≥1/2 screen width
Positive delay: 1 s to 5000 s
Timebase Mode
YT, XY, Roll
Number of X-Y
1
Waveform
Capture Rate
[2]
30,000 wfms/s (dots display)
Vertical
Bandwidth
(-3dB)
MSO/DS 1104Z/1104Z-S: DC to 100 MHz
MSO/DS 1074Z/1074Z-S: DC to 70 MHz
DS1054Z: DC to 50 MHz
Single-shot
Bandwidth
MSO/DS 1104Z/1104Z-S: DC to 100 MHz
MSO/DS 1074Z/1074Z-S: DC to 70 MHz
DS1054Z: DC to 50 MHz
Vertical
Resolution
Analog channe: 8 bit
Digital channel: 1 bit
Vertical Scale
1 mV/div to 10 V/div
Offset Range
(Probe ratio is
1X)
1 mV/div to 499 mV/div: ±2 V
500 mV/div to 10 V/div: ±100 V
Bandwidth
Limit
[1]
20 MHz
Low Frequency
Response
(AC Coupling,
-3dB)
≤5 Hz (on BNC)
Calculated Rise
Time
[1]
MSO/DS 1104Z/1104Z-S: 3.5 ns
MSO/DS 1074Z/1074Z-S: 5 ns
DS1054Z: 7 ns
DC Gain
Accuracy
[3]
<10 mV: ±4% full scale
≥10 mV: ±3% full scale
DC Offset
Accuracy
±0.1 div ±2 mV ±1% offset value
Channel to
Channel
Isolation
DC to maximum bandwidth: >40 dB
