RIGOL Chapter 18 Specifications
18-4 MSO1000Z/DS1000Z User’s Guide
Pulse Width
Range
8 ns to 10 s
Window Trigger (Option)
Window Type
Rising, Falling, Rising/Falling
Trigger Position
Enter, Exit, Time
Window Time
8 ns to 10 s
Nth Edge Trigger (Option)
Edge Type
Rising, Falling
Idle Time
16 ns to 10 s
Edge Number
1 to 65535
Slope Trigger
Slope Condition
Positive Slope (greater than, lower than, within specific interval)
Negative Slope (greater than, lower than, within specific
interval)
Time Setting
8 ns to 10 s
Video Trigger
Signal Standard
NTSC, PAL/SECAM, 480P, 576P
Pattern Trigger
Pattern Setting
H, L, X, Rising, Falling
Delay Trigger (Option)
Edge Type
Rising, Falling
Delay Type
>, <, <>, ><
Delay Time
8 ns to 10 s
TimeOut Trigger (Option)
Edge Type
Rising, Falling, Rising/Falling
Timeout time
16 ns to 10 s
Duration Trigger (Option)
Pattern
H, L, X
Trigger
Condition
>, <, <>
Duration Time
8 ns to 10 s
Setup/Hold Trigger (Option)
Edge Type
Rising, Falling
Data Type
H, L, X
Setup Time
8 ns to 1 s
Hold Time
8 ns to 1 s
RS232/UART Trigger (Option)
Polarity
Normal, Invert
Trigger
Condition
Start, Error, Check Error, Data
Baud Rate
2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps, 57600
bps, 115200 bps, 230400bps, 460800bps, 921600bps, 1Mbps
and User
