RIGOL Chapter 18 Specifications
18-6 MSO1000Z/DS1000Z User’s Guide
Math Operation
Waveform
Operation
A+B, A-B, A×B, A/B, FFT, A&&B, A||B, A^B, !A, intg, Diff, Sqrt,
Lg, Ln, Exp, Abs
FFT Window
Function
Rectangle, Hanning, Blackman, Hamming, Flat Top, Triangle
FFT Display
Half, Full
FFT Vertical
Scale
dB/dBm, Vrms
Number of
Buses for
Decoding
2
Decoding Type
Parallel (standard), RS232/UART (option), I2C (option), SPI
(option)
Display
Screen Type
7.0 inch (203 mm) TFT LCD display
Display
Resolution
800 Horizontal ×RGB×480 Vertical Pixel
Display Color
160,000 Color (TBD)
Persistence
Time
Min, 100 ms, 200 ms, 500 ms, 1 s, 5 s, 10 s, Infinite
Display Type
Dots, Vectors
I/O
Standard Ports
USB HOST, USB Device, LAN, Aux Output (TrigOut/PassFail),
GPIB (use USB HOST interface to expand)
Singnal Source (MSO1000Z-S/DS1000Z-S)
Channels
2
Sample Rate
200 MSa/s
Vertical
Resolution
14 bits
Max. Frequency
25 MHz
Standard
Waveform
Sine, Square, Pulse, Ramp, Noise, DC
Built-in
Waveform
Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Lorentz,
Haversine
Sine
Frequency Range
0.1 Hz to 25 MHz
Flatness
±0.5 dB (relative to 1 kHz)
Harmonic
Distortion
-40 dBc
Stray
-40 dBc
