Chapter 4 To Set the Sample System RIGOL

MSO1000Z/DS1000Z User’s Guide 4-5

3. Waveform Leakage: when the sample rate is too low, the waveform rebuilt

from the sample data does not reflect all the actual signal information.

Pulse

disappeared
