RIGOL Chapter 5 To Trigger the Oscilloscope
5-14 MSO1000Z/DS1000Z User’s Guide
line-by-line sweep.
Trigger Mode:
Press Sweep to open the trigger mode list and select auto, normal or single. For the
details, please refer to “
Trigger Mode”. The corresponding status light of the
current trigger mode turns on.
Trigger Setting:
Press Setting to set the trigger parameter (noise rejection) under this trigger type.
Trigger Level:
Use TRIGGER LEVEL to modify the level. For the details, please refer to the
introduction of “
Trigger Level”.
For a better observation of the waveform details in the vedio signal, you can
set a larger memory depth first.
In the trigger debugging process of vedio signals, the frequencies in different
parts of the signal can be reflected by different brightnesses as RIGOL digital
oscilloscopes provides the multi-level gray scale display function. Experienced
users can quickly judge the signal quality and discover abnormalities.
