Rigol MSO5000-E Series Service Guide

Chapter 1 Disassembly and Assembly RIGOL
MSO5000-E Service Guide 1-3
Table 1-1 Replacement Parts List
No.
Part No.
Qty.
Name/Description
1
2010003948
5
Small Knob
2
2010003946
3
Large Knob
3
2010004525
1
Panel
4
1020004598
1
Rubber Keypad
5
1010006312
1
LCD (Touch Screen Included)
6
1020004389
1
LCD Shield
7
1020004387
1
Metal Front Panel
8
1010006317
1
Power Cord Connector
9
2010004319
1
Power Key
10
1010006316
1
Mechanical Switch
11
2010004523
1
Main Board
12
2010003929
1
Handle
13
2010000182
2
Handle Shaft
14
2010002909
2
Anti-skid Pad
15
2010000979
2
Bracket
16
2010004526
1
Rear Panel
17
1020004391
1
Shield
18
2010004270
1
Power Supply Board
19
1020003428
1
M4x8 Torx Pan Head Combination Screw
20
1020002000
1
Fan
21
1020004388
1
Metal Rear Panel
22
1020003198
4
PTF5x10 Torx Flat Countersunk Head
Self-tapping Screw
23
1020000573
53
M3x8 Torx Pan Head Combination Screw
24
1020000648
4
BNC Lock Washer
25
1020000619
4
BNC Nut
26
2010004524
1
Keypad Board
The recommended disassembly procedures are as follows:
Disassemble the Rear Panel Components  Disassemble the Shield and Power Supply Board 
Disassemble the Metal Rear Panel Components  Disassemble the Fan  Disassemble the Knob 
Disassemble the Panel  Disassemble the Main Board  Disassemble the LCD  Disassemble the
Keypad Board  Disassemble the Power Key.
