Explanation for 4 X register :
Address Parameter Description
Demand Reset is used to reset the Demand parameter. A value
of zero must be Written to this register to reset the Demand
period. Writing any other value will return an error.
40001
Demand Reset
40003
Demand Period Demand period represents demand time in minutes. The
applicable values are 8,15,20 or 30. Writing any other value will
return an error.
40005
40007
System Voltage
This address is read only and displays System Voltage
40009
System Current
This address is read only and displays System Current
This address is used to set the System type.
Write one of the following value to this address.
1 = 1 Phase 2 Wire (Read only for 1P2W)
2 = 3 Phase 3 Wire 3 = 3 Phase 4 Wire.
Writing any other value will return error .
40011
System Type
40013
Pulse Width
of Relay
This address is used to set pulse width of the Pulse output.
Write one of the following values to this address:
60 : 60 ms
100 : 100 ms
200 : 200 ms
Writing any other value will return error .
40015
Reset
Parameters
This address is used to reset the parameters by writing following.
0 : Energy reset 1 : Demand reset 2 : Sys. Min reset
3 : Sys. Max reset 4 : RUN/ON hour reset 5 : No. of intr.
6 : Reset all Writing any other value will return an error.
Energy display
on Modbus
This address is used to set energy display on MODBUS in Wh,
KWh & Mwh. Write one of the following value to this address.
1 = Energy in Wh. 2 = Energy in KWh.
3 = Energy in MWh.
68
