RKC INSTRUMENT CB100 Initial Setting Manual

2. SETTING
IMCB04-E10
17
 Input range table
Thermocouple input (TC)
Type Input range
0 to 200 °C
0 to 400 °C
0 to 600 °C
0 to 800 °C
0 to 1000 °C
0 to 1200 °C
0 to 1372 °C
0 to 100 °C
0 to 300 °C
0 to 450 °C
0 to 500 °C
0.0 to 800.0 °C
4
0 to 800 °F
0 to 1600 °F
0 to 2502 °F
K
20 to 70 °F
0 to 200 °C
0 to 400 °C
0 to 600 °C
0 to 800 °C
0 to 1000 °C
0 to 1200 °C
0 to 450 °C
0 to 800 °F
0 to 1600 °F
0 to 2192 °F
0 to 400 °F
J
0 to 300 °F
0 to 1600 °C
1
0 to 1769 °C
1
0 to 1350 °C
1
0 to 3200 °F
1
R
0 to 3216 °F
1
0 to 1600 °C
1
0 to 1769 °C
1
0 to 3200 °F
1
S
0 to 3216 °F
1
B 400 to 1800 °C
3
Type Input range
0 to 1820 °C
1, 3
800 to 3200 °F
3
B
0 to 3308 °F
1, 3
0 to 800 °C
0 to 1000 °C
0 to 1600 °F
E
0 to 1832 °F
0 to 1200 °C
0 to 1300 °C
0 to 2300 °F
N
0 to 2372 °F
−199.9 to +400.0 °C
2
−199.9 to +100.0 °C
2
−100.0 to +200.0 °C
0.0 to 350.0 °C
−199.9 to +752.0 °F
2
−100.0 to +200.0 °F
−100.0 to +400.0 °F
0.0 to 450.0 °F
T
0.0 to 752.0 °F
0 to 2000 °C
3
0 to 2320 °C
3
W5Re/W26Re
0 to 4000 °F
3
0 to 1300 °C
0 to 1390 °C
0 to 1200 °C
0 to 2400 °F
PL II
0 to 2534 °F
−199.9 to +600.0 °C
2
−199.9 to +100.0 °C
2
0.0 to 400.0 °C
−199.9 to +999.9 °F
2
−100.0 to +200.0°F
U
0.0 to 999.9 °F
0 to 400 °C
0 to 800 °C
0 to 800 °F
L
0 to 1600 °F
1
0 to 399 °C (0 to 799 °F): Accuracy is not guaranteed.
2
−199.9 to −100.0 °C (−199.9 to −158.0 °F): Accuracy is not guaranteed.
3
Can’t be selected for the instrument with the modbus communication specification. (Z-1021 specification)
4
Input type K (0.0 to 800.0 °C) is selectable when Z-1038 specification is used.
