2. SETTING
IMCB04-E10 21
(6) AH2 (Alarm 2 [ALM2] differential gap setting)
Not displayed when there is no alarm 2 (ALM2).
Setting range
TC and RTD inputs: 0 to 100 °C [°F] or 0.0 to 100.0 °C [°F]
Voltage and current inputs: 0.0 to 10.0 % of span
Factory set value
TC and RTD inputs: 2 °C [°F] or 2.0 °C [°F]
Voltage and current inputs: 0.2 %
(7) CTr (CT ratio setting)
Not displayed when there is no heater break alarm (HBA).
Set the number of times that a wire is wound on to the hole of a CT.
Setting range: 0 to 9999
Factory set value: CTL-6-P-N: 800
CTL-12-S56-10L-N: 1000
(8) dF (Digital filter setting)
Setting range: 0 to 100 sec (If 0 is set, the PV digital filter is turned off.)
Factory set value: 1
(9) STTM (Time factor assumed to be safe)
Displayed when the self-tuning is provided.
As this factor is so adjusted that the self-tuning result optimum to most
controlled-objects is obtained, do not change it.
This is the factor to adjust the reference time of establishing the stabilized state of a measured value.
The larger the set value, the longer the time until the measured value is stabilized.
Setting range: 0 to 200
Factory set value: 100
