RKC INSTRUMENT CB100 Initial Setting Manual

3. COMMUNICATION INITIAL IDENTIFIER
IMCB04-E10
26
ID: Identifier (RO: Read only R/W: Read/write)
Name ID Data range Factory
set value
R/W
Time factor assumed to be safe
[STTM]
GH 0 to 200 100 R/W
Factor to calculate proportional band
[STPK]
PU 0 to 200 67 R/W
Factor to calculate integral time [STIK] IU 0 to 200 16 R/W
Integral time limiter [ILIM] IL 4 to 3600 seconds 3600
Z-1022
specification:
500
R/W
Holding peak ambient temperature
[TCJ]
HP
−10 to +100 °C
0 RO
Operating time display unit
(Upper digits) [WTH]
UT 0 to 10 0 RO
Operating time display unit
(Lower digits) [WTL]
UU 0 to 9999 0 RO
*1 Input type table
Input type Set value
K 0
J 1
L 2
E 3
N 4
T 5
U
a
6
R 7
S 8
B
b
9
W5Re/W26Re
b
10
Thermocouple
input (TC)
PL II 11
Pt100 Ω (JIS/IEC)
12
RTD input
(RTD)
JPt100 Ω (JIS)
13
0 to 5 V DC 14
0 to 10 V DC
c
14
Voltage input
1 to 5 V DC 15
0 to 20 mA DC 14
Current input
4 to 20 mA DC 15
a
6 is K input (0.0-800.0 °C) when Z-1038 specification is used.
(Type U input is not available with Z-1038 specification.)
b
Can’t be selected for the instrument with the modbus communication specification (Z-1021
specification).
c
To be fixed to 14 for the 0 to 10 V DC (Z-1010 specification). No input type cannot be changed as
the hardware differs.
