1.1 RECOMMENDED ACCESSORIES
Lithium TOP Equalizer 6S and
12S: an absolutely essential
accessory for charging Lithium
and Lithium-Polymer batteries.
The Equalizer evens out differen
ces in cell voltages during the
charge process, and prevents indi
vidual cells becoming overchar
ged. The charger features an
Equalizer sensor socket, so that a
graphic and numeric display of
individual cell voltages can be dis
played on the charger’s integral
screen.
Two TOP Equalizer 6S units can
be wired together (cascaded)
using a Master - Slave lead to
produce a 2 x 6 = 12S TOP
Equalizer.
Operating Instructions
POWER PEAK Infinity 3
No.
8429
4
Transmitter battery charge
lead BID chip, excl. lead,
for No. F1415
Receiver battery charge
lead No. F1416
Power Peak SPS 7A mains PSU
No. 8415
Connecting the battery charger to the
Power Peak SPS 7A mains PSU con-
verts the unit into a mains-powered
charger. When used with this power
source, the charger’s maximum cur-
rents at high cell-counts are limited.
BID chip, excl. lead, for
fitting to additional batte-
ries No. 8472
BID chip, incl. 300 mm
lead, for fitting to additio
-
nal batteries
No. 8473
BID lead, 300 mm
No. 8474
BID lead, 500 mm
No. 8475
Lithium TOP Equalizer 12S, No. 8484 for 2 - 12S packs
Lithium TOP Equalizer 6S, No. 8488, for 2 - 6S packs; can be cas-
caded to 2 x 6S = 12S using a Master - Slave connection
