Activate the ‘DISCHARGE VOLTAGE’ line, and you can
define the final discharge voltage to suit the battery type
by rotating the hotkey. Changes are made in increments
of 0.1 V.
• Nickel-Cadmium battery (NiCd): 0.1 - 1.1 V / cell
• Nickel-Metal Hydride battery (NiMH): 0.1 - 1.1 V / cell
• Lithium or Lithium-Polymer battery (LiPo): 2.5 - 3.7 V / cell
• Lead-acid battery (Pb): fixed, 1.8 V / cell
Activate the ‘PEAK SENSITIVITY’ line, and you can pro-
gram the sensitivity of the automatic charge cut-off circuit
for NiCd and NiMH batteries by rotating the hotkey.
• Nickel-Cadmium battery (NiCd): 5 - 25 mV / cell
• Nickel-Metal Hydride battery (NiMH): 3 - 15 mV / cell
In the case of NiMH batteries it is also possible to select
ZEROpk (Zero peak); in this mode a very low peak sensi-
tivity of 2 mV / cell is used.
Activate the ‘CUT-OFF TEMPERATURE’ line, and you can
rotate the hotkey to set the maximum battery temperatu-
re at which a process is to be terminated. If you wish to
use this facility, you must attach the temperature sensor
(supplied) to the battery. The available temperature range
is 10°C to 65°C in increments of 1°C.
In the ‘MAX CAPACITY’ line you can define the maximum
capacity which can be charged in or discharged, in the
form of a percentage value relating to the set battery
capacity. The adjustment range is 10 … 150% for NiCd
and NiMH batteries, and 10 … 120% for Lithium and
Lead-acid batteries. Entering a value at this point limits
the quantity of energy which can be charged into a pack,
and this feature can also be used as a means of avoiding
overcharging. The charger simply terminates the process
as soon as the pre-set value is reached.
If you activate the ‘PEAK DELAY’ line, it is possible to
activate a pre-peak suppression for NiCd and NiMH bat-
teries with a rotary movement. This prevents a premature
cut-off at the start of the charge process when dealing
with batteries with high inter
nal resistance. The delay can
be set to any value within the range 1 … 20 minutes in
increments of one minute.
