R. Gobo Index 2/6 channel 71
Colour wheel 1 channel 72
Colour wheel 2 channel 73
Prism 1 channel 74
Prism 2 channel 75
Zoom channel 76
Focus channel 77
Iris channel 78
Frost 1/1 channel 79
Frost 1/2 channel 80
Frost 2/1 channel 81
Frost 2/2 channel 82
Fr. Shutters rot. channel 83
Fr. Shutter 1 Move channel 84
Fr. Shutter 1 swiveling. channel 85
Fr. Shutter 2 Move channel 86
Fr. Shutter 2 swiveling channel 87
Fr. Shutter 3 Move channel 88
Fr. Shutter 3 swiveling channel 89
Fr. Shutter 4 Move channel 90
Fr. Shutter 4 swiveling channel 91
Calibrate Fr. Hysteresis
Framing Lamella 1 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 2 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 3 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 4 - a framing lamella 1 reverse movement (value range: 0-8)
The value set for every framing lamella gives a value at which the lamella reacts to its reverse
movement promptly (without movement hysteresis).
Calibrate Pan/Tilt EMS - The menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Calibrate Pan/Tilt Reset - The menu item is used for calibration of pan/tilt reset in factory and also has to
be used in case of changing of pan or tilt motor.
Load Default Calibrations - The item loads default (factory) calibration values.
Rotating Gobos Change - This menu makes changing of rotating gobos in the xture easier.
Gobo Carousel 1 - The menu allows movement of rotating gobos on the gobo carousel 1 to positions suitable
for their changing.
G1-Mg - a movement of the gobo 1 (gobo holder with magnet) to the changing position.
G2 - a movement of the gobo 2 to the changing position.
:
Gobo O󰀨set -a gobo o󰀨set setting. The function allows ne swiveling of the gobo holder. The set value
is valid for all gobos on the gobo carousel 1.
Gobo Carousel 2 - The menu allows movement of rotating gobos on the gobo carousel 2 to positions suitable
for their changing.
G1-Mg - a movement of the gobo 1 (gobo holder with magnet) to the changing position.
G2 - a movement of the gobo 2 to the changing position.
:
Gobo O󰀨set -a gobo o󰀨set setting. The function allows ne swiveling of the gobo holder. The set value
is valid for all gobos on the gobo carousel 2.
LEDs Measure - This menu item runs a procedure which measures a light intensity of the LEDs module installed
in the xture. This procedure takes about 1 minute (message " LEDs Module Measurement" is displayed on
the screen"). During the procedure the xture does not receive DMX signal, pan/tilt go to 128 DMX, a shutter
is open and a dimmer is set at max. light intensity (255 DMX). All e󰀨ects are taken out from the light beam.
The measured light intensity is recorded in the item Intensity in the menu LED Module Info:
Tab Information --> Actual Module Info --> Intensity
Tab Information --> Intensity History --> Intensity
The light intensity in the menu item Intensity is displayed in percentages in relation to the initial intensity of the
