The Regal is Robinsons new 12ft (3836mm) wide
greenhouse with lengths from 8ft (2632mm) upwards in
2ft (610mm) increments. There is no limit on the length.
Ridge and eave brackets are applied to every set of glazing
bars and extra structural support is added to the door
gable by 8ft (2632mm) purlin bar. Fixed to the glazing bars
with slide in nuts and bolts.
If extensions are added (these being 6ft (1860) models),
a strengthening ‘A’ frame must be attached.
It is essential that a large greenhouse of this span has a
continuous concrete or brick perimeter footing.
DOOR FIXING
When fixing the door top track bar, it is necessary to drill
holes in door track into glazing bar, and fix with long self
tap screws (No.8 x
3
/4).
A 10’ and 12’ long house each only
‘A’ Frame as standard.
15
REGAL
MODEL Normal size ‘A’ Frame Max Span
8 + 6 14 One 8’
10 + 6 16 Two 6’
12 + 6 18 Two 6’
8 + 6 + 6 20 Two 8’
10 + 6 + 6 22 Three 6’
12 + 6 + 6 24 Three 6’
SIZE
•
REGAL 12
‘A’ FRAME
Regal 12 x 24 Example
‘A’ Frame
‘A’ Frame
‘A’ Frame
12ft House 6ft Ext 6ft Ext
12ft
Eave Brace
x 16
Roof Tile
x 8
Gable
Purlin 12ft
Gable Purlin 8ft over doors
NB. Longer self tap screws for door track No.8 x
3
/4”
