Robitronic Expert LD 80 - 2 Exterior of the Unit

-
26
-
Input power cable
AC 100-240V
Input power cable
DC 11~18V
LCD Screen
(16 chr., 2 rows)
3-pin port for
temperature
SELECT / STOP
To select main program
To stop the operation
DEC / INC
To select sub program
to alter the value
START / ENTER
To resume or start the
operation
Charging lead connector
(4mm banana female)
Individual cell
connector port
2. Exterior of the unit
