Robotiq Hand-E Gripper Instruction Manual
6.3. Rack &pinion mechanism cleaning
Maintenance Interval Tools You Need Parts You Need
Every 2M cycles or more frequently
in dirty operating conditions
l 4 mm hex key
l Dry tissue or towel
l Low strength thread locker
l Grease (Mobilith SHC1500 or
equivalent.)
None (unless damage is detected)
Caution
Always turn off the robot and the gripper power supply before performing any maintenance operations.
1. Open the gripper to an intermediate position, so you do not hide the six (6) M4 screws holding the rack housing in place.
2. Remove the gripper from its coupling using the 4 mm hex key to unscrew the four (4) M5-0.8 x 25mm screws. Note that each
screw uses a tooth lock washer, do not lose them.
3. Remove the six (6) M4 screws holding the rack housing.
4. Gently pull the rack housing away from the body of the gripper.
5. The finger's racks will slide off freely from the rack housing. Clean the rack housing, the racks and the pinion using a
degreaser. Dry thoroughly. Clean the fingers (finger holders and fingertips if that is the case) with a dry towel. Remove all
debris, dirt and dust
6. Clean the coupling with a dry towel, pay particular attention to the electrical contact.
7. Clean the gripper according to the procedure described in the Gripper cleaning section.
8. Visually inspect the gripper and pay attention to any visible damage.
9. Apply grease on the racks. Put it on all surfaces except the face with the tapped holes.
Info
Use Mobilith SHC1500 grease or an equivalent.
10. Slide the racks back in the rack housing.
11. Reinsert the rack housing with racks on the gripper. Make sure the racks go in symmetrically compared to the center of the
gripper. As a reference, both distances d represented in the figure below should be the same.
96
