First start-up
44
5
Table5.1 R15 gas valve setting table
Gas
Gas network
pressure
Screw pre-adjustment Oset pressure CO
2
percentage in fumes
Throttle Oset nominal Minimal heat input Nominal heat input
Type mbar
turns turns
Pa % %
G20
See Table
3.1 p.29
-10 ½ -3 ¾ -10 8,7 9,3
G25 full open -3 -5 8,6 9,2
G25.1 -10 ½ -3 ¾ -10 10,2 10,7
G25.3 full open -3 ¾ -10 8,6 9,2
G27 -12 -3 ¾ -10 9,0 9,5
G2.350 full open -3 ¾ -10 8,6 9,1
G30 -7 -3 ¾ -10 9,9 10,3
G31 full open -3 ¾ -10 10,0 10,5
LPG -9 -3 ¾ -10 9,9 10,5
A tolerance of ±0,3% is applied to all values of CO
2
percentage in fumes.
Table5.2 R20 gas valve setting table
Gas
Gas network
pressure
Screw pre-adjustment Oset pressure CO
2
percentage in fumes
Throttle Oset nominal Minimal heat input Nominal heat input
Type mbar
turns turns
Pa % %
G20
See Table
3.1 p.29
-3 ¾ -3 ¾ -10 8,6 9,2
G25 full open -3 ¾ -10 8,7 9,3
G25.1 -5 ¼ -3 ¾ -10 10,6 11,1
G25.3 -7 ½ -3 ¾ -10 8,5 9,1
G27 -5 ½ -3 ¾ -10 9,1 9,6
G2.350 full open -3 ¾ -10 8,8 9,3
G30 -2 ¼ -3 ¾ -10 9,9 10,3
G31 full open -3 ¾ -10 10,5 11,0
LPG -2 ¾ -3 ¾ -10 10,3 10,7
A tolerance of ±0,3% is applied to all values of CO
2
percentage in fumes.
Table5.3 R30 gas valve setting table
Gas
Gas network
pressure
Screw pre-adjustment Oset pressure CO
2
percentage in fumes
Throttle Oset nominal Minimal heat input Nominal heat input
Type mbar
turns turns
Pa % %
G20
See Table
3.1 p.29
-6 ½ -3 ¾ -10 8,5 9,0
G25 full open -3 ¾ -10 8,5 9,0
G25.1 -13 ½ -3 ¾ -10 9,6 10,1
G25.3 -21 -3 ¾ -10 8,5 9,0
G27 -6 ¾ -3 ¾ -10 8,5 9,0
G2.350 full open -3 ½ -8 8,5 9,0
G30 -8 -3 ¾ -10 9,5 11,0
G31 full open -3 -5 9,1 9,5
LPG -14 -3 ½ -8 9,0 9,6
A tolerance of ±0,3% is applied to all values of CO
2
percentage in fumes.
Table5.4 R40 gas valve setting table
Gas
Gas network
pressure
Screw pre-adjustment Oset pressure CO
2
percentage in fumes
Throttle Oset nominal Minimal heat input Nominal heat input
Type mbar
turns turns
Pa % %
G20
See Table
3.1 p.29
-5 -3 ¾ -10 8,6 9,2
G25 full open -3 ¼ -7 8,5 9,0
G25.1 -8 ¼ -3 ¾ -10 9,6 10,2
G25.3 -12 -4 -10 8,5 9,0
G27 -8 ½ -3 ¾ -10 8,6 9,1
G2.350 full open -3 ¾ -10 8,5 9,0
G30 -8 -3 ¾ -10 9,5 10,0
G31 full open -3 -5 9,6 10,1
LPG -10 ¼ -4 -12 9,5 10,1
A tolerance of ±0,3% is applied to all values of CO
2
percentage in fumes.
