Robustel GoRugged M1000 User Guide
RT_UG_M1000 Standard_v.2.0.0 20.12.2013 37 / 83
Confidential
DO
Item
Description
Default
Alarm Source
Digital Output acts according to different alarm source.
Selected from DI Alarm, SMS Control, Call Control, selection can be
one or more.
DI Alarm: Digital Output triggers the related action when there is
alarm from Digital Input.
SMS Control: Digital Output triggers the related action when
receiving SMS from the number in the phone book.
Call Control: Digital Output triggers the related action when receiving
phone call from the number in the phone book.
Null
Alarm On Action
Digital Output acts when there is an alarm.
Selected from OFF, ON, Pulse, Null.
OFF: Open when triggered.
ON: Short contact when triggered.
Pulse: Generates a square wave as specified in the pulse mode
Null
