Robustel GoRugged R3000-3P User Manual

Robustel GoRugged R3000-3P User Guide
23
PIN code request
After click this button, you could input your SIM’s PIN and store the current
PIN in its memory, and then enter the PIN automatically each time the
system boots up.
Note: Please ask your local ISP to see whether your SIM card requiring
PIN or not.
If you want to change the SIM PIN, please click the button to enable it, and
then input the new PIN.
Null
Connection Mode
Connection Mode
Select from “Always Online” and “Connect On Demand”.
Always Online: Router will automatically to establish a 3G connection
after power on and each restarts, this will remain and will be re-established
after an interruption.
Connect On Demand: After selection this option, user could configure
Triggered by Serial Data, Triggered by Periodically Connect and Triggered by
Time Schedule.
Note: If you select several connect on demand polices, router only have to
meet one of them to be triggered.
Connect
On
Demand
Redial Interval
Router will automatically re-connect with this interval when it fails
communicating to peer via TCP or UDP
30
Max Retries
The maximum retries times for automatically re-connect when router fails
to dial up.
After maximum retries, router will reboot the wireless module. If router still
cannot dial up successfully, it will try to switch to the other SIM card. Then
router will re-connect with the other SIM card with maximum retries.
When connecting successful, the Max Retries counter will be set to 0.
3
Inactivity Time
You can configure this field after setting router under “Connect On
Demand” mode.
This field specifies the idle time setting for 3G auto-disconnection and
trying to revert back to preferred SIM card.
0 means timeless.
0
Serial Output Content
The content which output to the serial device which connect to router and
inform it that router is ready to receive serial data.
Null
Triggered by Serial Data
Tick this check box to allow router automatic connects to cellular network
from idle mode when there is data come out from serial port.
Enable
Triggered by Tel
Tick this check box to allow router automatic connects to cellular network
from idle mode when make a voice call to router.
Disable
Triggered by SMS
Tick this check box to allow router automatic connects to cellular network
from idle mode when send a specific SMS to router.
Disable
SMS Connect Command
Users shall send this specific SMS to trigger router to connect to cellular
network.
Null
SMS Disconnect
Command
Users shall send this specific SMS to trigger router to disconnect to cellular
network.
Null
SMS Connect Reply
When router connect to cellular network, it will automatically send out this
SMS to specific users (set in the Phone Group).
Null
