Robustel GoRugged R3000-3P User Manual

Robustel GoRugged R3000-3P User Guide
27
ISP Profile
This section allow users to preset some ISP profiles which will be shown in the selection list of
“Configuration”->”Cellular WAN”->”Network Provider Type”.
Cellular WAN @ Basic
Item
Description
Default
ISP
Input the ISP’s name which will be shown in the selection list of
“Configuration”->”Cellular WAN”->”Network Provider Type”.
Null
APN, Username,
Password, Dialup No.
All these parameters were provided by the ISP.
Null
3.12 Configuration -> Ethernet
This section allows users to set the Ethernet WAN and LAN parameters.
Eth0@Ethernet
Item
Description
Default
Ethernet Interface Type
Eth0 can work under two different kinds of mode: LAN and WAN.
LAN
Enable Bridge @ LAN
Interface
Enable to make Eth0 works under bridge mode with Eth1. Eth0 and
Eth1 will have the same IP address under this mode.
Enable
IP Address, Netmask,
MTU @ LAN Interface
Set the IP address, Netmask and MTU of Eth0/Eth1. These parameters
will be un-configurable if you enable Bridge.
Null
Multiple IP Address @
Assign multiple IP addresses for Eth0/Eth1.
Null
