Robustel GoRugged R3000-3P User Guide
86
INTERFACE MODE:
R3000-3P(config)# interface Ethernet 0
R3000-3P(config-e0)# ? //check what commands can be used in interface mode
exit Exit from current mode
end Exit to Normal mode
ip Set the IP address of an interface
mtu Set the IP address of an interface
5.2 How to configure the CLI
Following is a list about the description of help and the error should be encountered in the configuring program.
Typing a question mark “?” everywhere needed that will show us the helpful
information.
Press these two keys at the same time , except its “copy” function but also
can be used for “break” out of the setting program .
Parameters “xxx” are not supported by the system , in this case, enter a mark
“?” instead of “xxx” will help to find out the correct parameters about this
issue.
Parameters haven’t been finished yet .
% Invalid input detected at '^' marker
'^' marker indicates the location where is set wrong .
Note: Almost all the parameters setting are in the Global configuration mode ,commands set ,add are very
important for this mode. If some parameters can’t be found in the Global configuration mode , please move back to
Privileged exec mode or move up to Interface mode .
NOTICE: Knowing the CLI hierarchy level modes is necessary before configuring the CLI. If you don’t , please
go back and read it quickly in chapter 5 !
5.2.1 QuickStart with configuration examples
The best and quickest way to master CLI is firstly to view all features from the webpage and then reading all CLI
commands at a time ,finally learn to configure it with some reference examples .
Example 1 : Show current version
R3000-3P> show version
software version : 1.01.00
kernel version : v2.6.39
hardware version : 1.01.00
Example 2 : Update firmware via tftp
