Robustel GoRugged R3000-3P User Guide
33
and send the data to the Cellular WAN/Ethernet WAN when a specific
character, entered in hex format, is received. A second delimiter character
may be enabled and specified in the Delimiter 2 field, so that both characters
act as the delimiter to control when data should be sent.
Delimiter1 (Hex) @
Transparent
Enter the delimiter in Hex.
0
Delimiter Process @
Transparent
The Delimiter process field determines how the data is handled when a
delimiter is received.
None: Data in the buffer will be transmitted when the delimiter is received;
the data also includes the delimiter characters.
Strip: Data in the buffer is first stripped of the delimiter before being
transmitted.
Strip
Local Port @ Modbus
Enter the Local port for Modbus.
0
Attached serial device
type @Modbus
Select From “Modbus RTU slave”, “Modbus ASCⅡ slave”, “Modbus RTU
master” and “Modbus ASCⅡ master”.
Modbus RTU slave: router connects to slave device which works under
Modbus RTU protocol.
Modbus ASCⅡ slave: router connects to slave device which works under
Modbus ASCⅡprotocol.
Modbus RTU master: router connects to master device which works under
Modbus RTU protocol.
Modbus ASCⅡ master: router connects to master device which works under
Modbus ASCⅡ protocol.
Modbus Slave @
Modbus
Add the Modbus slaves which will be polled by Modbus master (router). This
section only displayed when you select “Modbus RTU master” or “Modbus
ASCⅡ master” in “Attached serial device type”.
Null
Slave Address
This connection is usually used to connect to the Modbus slave devices which
as TCP server. Enter IP address of the TCP server.
Null
Slave Port
Enter the port number of TCP server.
Null
ID
Enter the ID number of TCP server.
Null
