Rockchip RK3566 EVB2 - Audio MIC Array Signal Definition; Extension Interfaces

Copyright 2021 @ Rockchip Electronics Co., Ltd. 28
Table 3-5 Audio MIC Array Signal Definition
1
VCC5V0_SYS
2
VCC5V0_SYS
3
VCCIO1
4
GND
5
GND
6
VCC_3V3
7
GND
8
AUD_GPIO_A_d
9
GND
10
AUD_I2S_MCLK
11
GND
12
AUD_I2S_SCLK_RX/PDM_CLK1
13
GND
14
AUD_I2S_SCLK_TX
15
GND
16
AUD_I2S_LRCK_RX/PDM_CLK0
17
GND
18
AUD_I2S_LRCK_TX
19
AUD_I2S_SDO0
20
AUD_I2S_SDO1
21
AUD_I2S_SDO2
22
AUD_I2S_SDO3
23
AUD_I2S_SDI0/PDM_SDI0
24
AUD_I2S_SDI1/PDM_SDI1
25
AUD_I2S_SDI2/PDM_SDI2
26
AUD_I2S_SDI3/PDM_SDI3
27
GND
28
AUD_GPIO_B_d
29
AUD_I2C_SDA
30
AUD_I2C_SCL
3.17 CIF/EBC/RGMII/BT656 Extension Interfaces
The development board reserves CIF, EBC, RGMII, BT656 and other signal extension interfaces to facilitate users to
debug the corresponding peripherals. If you need to change the extension interface, jumper resistors are needed, and
you need to add the resistors corresponding to the signal, and remove the resistors accordingly. Due to the large
number of networks, it will not go into much details here.
