Rocket DOPPIA 2GR - Data and Marking

USER'S MANUAL
11 of 28
2.7 Data and marking
The general technical data of the machines are given in the
following table:
2GR 3GR
Power 5 Kw 5.8 Kw
Services boiler capacity 9 l 12 l
Coffee boiler capacity 4 l 6,3 l
Services boiler pressure MIN 0.0 bar – MAX 1.50 bar
Coffee boiler temperature MIN 80 °C – MAX 100°C
Working environment temperature 5 - 35°C 95° R.H. MAX.
Sound pressure level < 70 dB
According to Directive 2006/42/EC, the machine is marked
with the CE marking by which the manufacturer declares un-
der his own responsibility that the machine is safe for persons
and property.
Alternative markings may be applied depending on the tar-
get markets in accordance with current product regulations.
The rating plate with the appropriate markings, on which the
identication data and specic technical data of the equip-
ment are shown, is afxed under the drip tray.
Below is an example of the rating plate.
For any communication with the manufacturer, always report
the following data:
• Machine Serial No.;
• Machine model
The equipment data are also visible on the label on the ma-
chine's packaging.
It is forbidden to remove or alter the rating
plate. If it is deteriorated or illegible, please con-
tact the manufacturer.
The rating plate is afxed to the
bottom right, at the front of the
machine, hidden under the drip tray.
MADE IN ITALY
Via Curiel, 13 20060 Liscate (MI)
rocket-espresso.com
ROCKET MILANO S.r.l.
Potenza: ______________
Pressione: ________________
Serial Nr. __________________________
Model:__________
