Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 137
Appendix A Specifications
4.000 3.672 3.968 3.640 3.904 125 Hz
8.000
(1)
7.312 7.868 7.280 7.804 63 Hz
16.000 14.592 15.668 14.560 15.604 31 Hz
(1) This is the default setting.
High-Speed DC Input Filter Settings (Inputs 0…11) (Continued)
Nominal Filter Setting (ms)
ON Delay (ms) OFF Delay (ms)
Maximum Counter Frequency (Hz) 50% Duty Cycle
Minimum Maximum Minimum Maximum
Standard DC Input Filter Settings (Inputs 4 and higher)
Nominal Filter Setting (ms)
ON Delay (ms) OFF Delay (ms)
Maximum Frequency (Hz) 50% Duty Cycle
Minimum Maximum Minimum Maximum
0.500 0.107 0.439 0.024 0.499 1.0 kHz
1.000 0.597 0.964 0.470 0.978 0.5 kHz
2.000 1.437 1.864 1.415 1.990 250 Hz
4.000 3.397 3.964 3.095 3.790 125 Hz
8.000
(1)
6.757 7.564 6.735 7.690 63 Hz
16.000 14.597 15.964 13.455 14.890 31 Hz
(1) This is the default setting.
Analog Input Filter Settings
Analog Input Filter Settings Filter Bandwidth (-3dB Freq Hz) Sampling Frequency
250 Hz 250 Hz 1 kHz
60 Hz 60 Hz 1 kHz
50 Hz 50 Hz 1 kHz
10 Hz 10 Hz 1 kHz
