CompactLogix Packaged Controllers 51
Publication 1769-IN082A-EN-P - July 2008
Open and short-circuit protection Yes
Maximum short-circuit Current: 40 mA
Maximum open circuit Voltage: 15V
Output response at system power-up
and power-down
+2.0V DC to -1.0V DC spike for less than 6 ms
Isolation voltage 30V (continuous), Basic Insulation Type
Type tested at 500V AC for 60 s; Inputs to System Backplane and
Outputs to System Backplane
Channel diagnostics Over-range by bit reporting
(1)
The over-range flag will come on when the normal operating range is exceeded. The will continue to convert the analog
output up to the maximum full scale range. The flag automatically resets when within the normal operating range.
(2)
Includes offset, gain, drift, non-linearity and repeatability error terms.
(3)
Output ripple is the amount a fixed output varies with time, assuming a constant load and temperature.
(4)
Repeatability is the ability of the output to reproduce output readings when the same value is applied to it consecutively,
under the same conditions and in the same direction.
Embedded HSC Input Specifications
Attribute Value
Input voltage range
-30 to +30V DC
(1)
(1)
See Maximum Input Voltage - 24V DC Operation temperature derating.
On-state voltage, max 30V DC
On-state voltage, min 2.6V DC
On-state current, min 6.8 mA
Off-state voltage, max 1.0V DC
Off-state current, max 1.5 mA
Off-state leakage current, max 1.5 mA
Input current, max 15 mA
Input current, min 6.8 mA
Input impedance (nominal) 1950 Ω
Pulse width, min 2.5 μsec
Phase separation, min 1.084 μsec
Input frequency, max 250 kHz
Isolation voltage 75V (continuous), Basic Insulation Type
Type tested at 1200V AC for 60 s; Inputs to System Backplane and
Input to Input
Embedded Analog Output Specifications
Attribute Value
