52 CompactLogix Packaged Controllers
Publication 1769-IN082A-EN-P - July 2008
Embedded HSC Output Specifications
Attribute Value
Output voltage range
5 to 30V DC
(1)
(1)
See Maximum Output Voltage - 24V DC Operation temperature derating.
On-state voltage, max User Power - 0.1V DC
On-state output current, max
1A per point
(2)
(2)
See Maximum Output Current per Point - 5V DC Operation temperature derating on page 54 and Maximum Output Current
per Point - 24V DC Operation temperature derating on page 55.
4A per module
(3)
(3)
See Maximum Output Current per Module - 5V DC Operation temperature derating on page 54 and Maximum Output
Current per Module - 24V DC Operation temperature derating on page 55.
On-state output current, min 1 mA
On-state voltage drop, max 0.5V DC
Off-state leakage current, max 5 µA
Turn-on time, max
400 µs
(4)
(4)
Maximum turn-on time applies to output voltage range of 5 to 7V DC. For output voltages greater than 7V DC, the maximum
turn-on time is 200 µs.
Turn-off time, max 200 µs
Reverse polarity protection 30V DC
Isolation voltage 75V (continuous), Basic Insulation Type
Type tested at 1200V AC for 60 s; Inputs to System Backplane
and Input to Input
Pilot duty rating Not rated
