Rockwell Automation Publication 2198-UM005C-EN-P - February 2022 23
Chapter 1 Start
Catalog Number Explanation Kinetix 5300 drive catalog numbers and performance descriptions.
Table 3 - Kinetix 5300 Servo Drives
Table 4 - Shared-bus Connector Kit Catalog Numbers
Table 5 - Kinetix 5300 Servo Drive Accessories
Drive Cat. No. Frame Size Input Voltage
Continuous Output Power
kW
Continuous Output Current
A (rms)
Peak Output Current
A (rms)
2198-C1004-ERS 1
85…132V rms single-phase
170…253V rms single-phase
170…253V rms three-phase
0.22
0.46
0.72
2.8
6.6
9.5
9.5
2198-C1007-ERS 1
0.36
0.76
1.18
4.6
9.7
15.5
15.5
2198-C1015-ERS 2
0.67
1.41
2.18
8.5
12.2
20.5
29.2
2198-C1020-ERS 2
0.97
2.02
3.13
12.2
25.0
40.6
40.6
2198-C2030-ERS 2
170…253V rms three-phase
5.02 19.6 61.0
2198-C2055-ERS 3 10.30 40.2 108.0
2198-C2075-ERS 3 12.22 47.7 127.5
2198-C4004-ERS 1
342…528V rms three-phase
0.86 1.6 5.3
2198-C4007-ERS 1 1.55 2.9 9.3
2198-C4015-ERS 2 2.78 5.2 18.0
2198-C4020-ERS 2 3.90 7.3 23.8
2198-C4030-ERS 2 6.25 11.7 34.1
2198-C4055-ERS 3 12.08 22.6 58.5
2198-C4075-ERS 3 14.70 27.5 73.5
Kit Cat. No. Frame Size Description
2198-TCON-24VDCIN36 1, 2, or 3 Control power input connector
2198-H040-P-T 1 or 2
Control power T-connector
Bus-bar connectors, quantity 2
2198-H070-P-T 3
Control power T-connector
Bus-bar connectors, quantity 2
Cat. No. Description
2198-K53CK-D15M 15-pin motor-feedback connector kit.
2198-CONKIT-PWR20
Connector set included with the Frame 1 and 2 drives (except 2198-C2030 drives).
Replacement sets are also available.
2198-CONKIT-PWR30 Connector set included with 2198-C2030 drives. Replacement sets are also available.
2198-CONKIT-PWR75 Connector set included with Frame 3 drives. Replacement sets are also available.
