94 Publication 2711C-UM001C-EN-P - September 2009
Appendix A Specifications
Environmental
Real-time clock
C200 and C300
C600 and C1000
No battery backup
Battery backup
Input voltage range 18…30V DC (24V DC nom)
Power consumption, max
C200 and C300
C600
C1000
5 W (0.21 A at 24V DC)
10 W (0.42 A at 24V DC)
18 W (0.75 A at 24V DC)
Weight, approx.
C200 function key
C200 keypad, C300 keypad
C300 touch
C600 touch
C1000 touch
0.19 kg (0.40 lb)
0.30 kg (0.65 lb)
0.20 kg (0.43 lb)
0.68 kg (1.48 lb)
1.57 kg (3.41 lb)
Dimensions (HxWxD), approx.
C200 function key
C300 touch
C200 keypad, C300 keypad
C600 touch
C1000 touch
80 x 116 x 54 mm (3.15 x 4.54 x 2.13 in.)
80 x 116 x 57 mm (3.15 x 4.54 x 2.23 in.)
119 x 139 x 55 mm (4.69 x 5.47 x 2.15 in.)
154 x 209 x 57 mm (6.0 x 8.23 x 2.25 in.)
250 x 308 x 54 mm (9.84 x 12.13 x 2.13 in.)
PanelView Component - 2711C-F2M, 2711C-K2M, 2711C-T3M, 2711C-K3M,
2711C-T6M, 2711C-T6C, 2711C-T10C
Attribute Value
Attribute Value
Temperature, operating 0…50 °C (32…122 °F)
Temperature, nonoperating -25…70 °C (13…158 °F)
Heat dissipation
C200 and C300
C600
C1000
16 BTU/hr
32 BTU/hr
58 BTU/hr
Relative humidity 0…95% noncondensing
Shock, operating 15 g at 11 ms
Shock, nonoperating 30 g at 11 ms
Vibration 2 g at 10…500 Hz
Enclosure type ratings NEMA/UL Type 4X (indoor) 12, 13, and IEC IP54, IP65
2711C-T6M, 2711C-T6C Series B only: NEMA/UL Type 12,
13, and IEC IP54
