Rockwell Automation Publication 2198-RM005A-EN-P - October 2020 11
Replacement Considerations Chapter 1
AC Input Power Cable Length
and Fuse Protection
This section provides information to assist in the determination of power
cable lengths and fuse protection for the drives.
AC Input Power Configuration
The Kinetix 350 drive supports multiple types of AC input power: center
grounded wye secondary, and corner grounded delta secondary.
The Kinetix 5300 drives only support AC input power with center grounded
wye secondary.
Input Power Cable Length and Fuse Protection
Determine the wire length for the AC line input after the drive location and
cable routing are finalized.
In general, the recommended drive replacement should not require changes in
wiring length; however, the routing may need to change as the input power
(Mains IPD) and motor power (MP) connections on the Kinetix 350 drives and
Kinetix 5300 could be in different physical locations with different
terminations. Table 5
gives an overview of the connection placement for
Kinetix 5300 drives. See Connectors
for a comparison of the Kinetix 350 and
Kinetix 5300 drive connectors.
Table 5 - Input and Motor Power Connection Placement for Kinetix 350 and Kinetix 5300 Drives
Series Input Power Location Motor Power Location
Kinetix 350 Top Front
Kinetix 5300 Top Bottom
