Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 105
Kinetix 5500 Servo Drives
Performance Specifications with 400V-class Drive Operation and Frame 70 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output
460V AC
kW
Kinetix 5500 Drives
(480V AC input)
LDAT-S072010-DDx 3.9
6.0
364 (82)
22.0
1055 (237)
1.37
2198-H025-ERSx
LDAT-S072020-DDx
5.0 1.64
LDAT-S072030-DDx
…
LDAT-S072070-DDx
LDAT-S072010-EDx
3.5 3.0 11.0 1.03 2198-H015-ERSx
LDAT-S072020-EDx
…
LDAT-S072070-EDx
LDAT-S073010-DDx 4.4
9.0
554 (125)
32.8
1576 (354)
2.27
2198-H040-ERSx
LDAT-S073020-DDx
…
LDAT-S073070-DDx
5.0 2.50
LDAT-S073010-EDx
…
LDAT-S073070-EDx
2.4 3.0 10.9 1.01 2198-H015-ERSx
LDAT-S074010-DDx 4.7
11.9
730 (164)
43.5
2088 (469)
3.15
2198-H040-ERSx
LDAT-S074020-DDx
…
LDAT-S074070-DDx
5.0 3.30
LDAT-S074010-EDx
…
LDAT-S074070-EDx
3.5 6.0 21.7 2.08 2198-H025-ERS
x
LDAT-S076010-DDx
5.0 18.2
1122 (252)
66.4
3189 (717)
5.02 2198-H070-ERSx
LDAT-S076020-DDx
…
LDAT-S076070-DDx
LDAT-S076010-EDx
…
LDAT-S076070-EDx
3.5 9.1 33.2 3.18 2198-H040-ERSx
