Kinetix 6200 and Kinetix 6500 Modular Servo Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
MPL-B660F 2000 3000 38.5 48.0 (425) 96.0 101 (895) 6.1 2094-BM05-M
MPL-B680D 2000 2000
30.0 55.4 (490) 75.0 125 (1105)
9.3
2094-BM03-M
34.0 62.8 (556) 94.0 154 (1365) 2094-BM05-M
MPL-B680F 2000 3000 47.9 60.0 (531) 96.0 108 (960) 7.5 2094-BM05-M
MPL-B680H 2000 3500 48.9 58.0 (513) 97.8 107 (947) 7.5 2094-BM05-M
MPL-B860D 2000 2000 47.3 83.0 (735) 95.5 152 (1350) 12.5 2094-BM05-M
MPL-B880C 1500 1500 47.5 110 (973) 97.5 203 (1800) 12.6 2094-BM05-M
MPL-B880D 2000 2000 48.9 79.9 (706) 96.0 147 (1300) 12.6 2094-BM05-M
MPL-B960B 1200 1200 42.5 130 (1150) 94.0 231 (2050) 12.7 2094-BM05-M
MPL-B980B 1000 1000 40.0 162 (1440) 94.0 278 (2460) 15.2 2094-BM05-M
Kinetix MPM Motor Performance Specifications with Kinetix 6200/6500 Drives
Motor Cat. No.
Speed, base
rpm
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPM-B1151F 3000 4000 5000 2.71 2.3 (20.3) 9.9 6.6 (58.4) 0.75 2094-BMP5-M
MPM-B1151T 6000 5000 7000 5.62 2.3 (20.3) 20.5 5.8 (51.3) 0.90 2094-BM01-M
MPM-B1152C 1500 2500 3000 3.61 5.0 (44.2) 12.4 13.5 (119) 1.20 2094-BM02-M
MPM-B1152F 3000 4000 5200 6.17 5.0 (44.2) 21.1 13.3 (118) 1.40 2094-BM01-M
MPM-B1152T 6000 4000 7000 11.02 5.0 (44.2) 36.5 13.1 (116) 1.40 2094-BM02-M
MPM-B1153E 2250 3000 3500 6.21 6.5 (57.5) 21.6 19.7 (174) 1.40 2094-BM01-M
MPM-B1153F 3000 4000 5500 9.20 6.4 (56.6) 32.0 19.7 (174) 1.40 2094-BM02-M
MPM-B1153T 6000 4000 7000 15.95 6.4 (56.6) 45.0 14.5 (128) 1.45 2094-BM03-M
MPM-B1302F 3000 4000 4500 8.57 6.6 (58.4) 21.5 13.0 (115) 1.65 2094-BM01-M
MPM-B1302M 4500 4000 6000 12.57 6.6 (58.4) 32.4 13.3 (118) 1.65 2094-BM02-M
MPM-B1302T 6000 4000 7000 16.83 6.7 (59.3) 43.4 13.3 (118) 1.65 2094-BM03-M
MPM-B1304C 1500 1870 2750 7.00 10.3 (91.1) 21.5 26.4 (233) 2.00 2094-BM01-M
MPM-B1304E 2250 3500 4000 10.75 10.2 (90.3) 34.2 27.1 (240) 2.20 2094-BM02-M
MPM-B1304M 4500 3500 6000 19.02 10.4 (92.0) 60.6 27.1 (240) 2.20 2094-BM03-M
MPM-B1651C 1500 3000 3500 10.21 11.4 (101) 29.2 23.2 (205) 2.50 2094-BM02-M
MPM-B1651F 3000 3000 5000 17.75 11.4 (101) 50.9 23.2 (205) 2.50 2094-BM03-M
MPM-B1651M 4500 3000 5000 22.46 11.3 (100) 56.8 21.4 (189) 2.50 2094-BM03-M
MPM-B1652C 1500 2500 2500 11.51 16.4 (145) 33.6 40.2 (356) 3.80 2094-BM02-M
MPM-B1652E 2250 3500 3500 20.94 21.1 (187) 60.5 48.0 (425) 4.30 2094-BM03-M
MPM-B1652F 3000 3500 4500 28.74 21.1 (187) 84.1 48.0 (424) 4.30 2094-BM05-M
MPM-B1653C 1500 2000 2500 20.05 26.7 (236) 59.2 67.7 (599) 4.60 2094-BM03-M
MPM-B1653E 2250 3000 3500 27.00 26.8 (237) 72.9 62.0 (549) 5.10 2094-BM03-M
MPM-B1653F 3000 3000 4000 34.94 31.0 (274) 94.3 56.0 (495) 5.10 2094-BM05-M
MPM-B2152C 1500 2000 2500 27.40 36.7 (325) 55.4 72.2 (639) 5.60 2094-BM03-M
MPM-B2152F 3000 2500 4500 43.54 34.1 (302) 97.8 72.3 (495) 5.90 2094-BM05-M
MPM-B2152M 4500 2500 5000 44.58 34.1 (302) 76.3 52.9 (468) 5.90 2094-BM05-M
MPM-B2153B 1250 1750 2000 24.06 48.0 (425) 60.0 101 (894) 6.80 2094-BM03-M
MPM-B2153E 2250 2000 3000 39.63 47.9 (424) 97.8 101 (894) 7.20 2094-BM05-M
MPM-B2153F 3000 2000 3800 43.86 45.6 (403) 97.8 99.0 (875) 7.20 2094-BM05-M
MPM-B2154B 1250 1750 2000 35.46 62.7 (555) 97.8 154 (1362) 6.90 2094-BM05-M
MPM-B2154E 2250 2000 3000 43.68 55.9 (495) 97.8 112 (990) 7.50 2094-BM05-M
MPM-B2154F 3000 2000 3300 44.40 56.2 (497) 83.6 88.0 (778) 7.50 2094-BM05-M
Kinetix MPL Motor Performance Specifications with Kinetix 6200/6500 Drives (continued)
Motor Cat. No.
Rated Speed
rpm
Maximum
Speed
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
