174 Rockwell Automation Publication KNX-SG001H-EN-P - December 2020
Kinetix 6200 and Kinetix 6500 Modular Servo Drives
Performance Specifications (frame 100) with Kinetix 6200/6500 Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient temperature and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output 460V
AC
kW
Kinetix 6200/6500
400V-class Drives
LDAT-S102010-DBx 3.4
5.7
456 (103)
21.0
1289 (290)
1.44
2094-BM01-M
LDAT-S102020-DBx 4.4 1.74
LDAT-S102030-DBx
5.0 1.91
LDAT-S102040-DBx
LDAT-S102050-DBx
…
LDAT-S102090-DBx
LDAT-S102010-EBx
…
LDAT-S102090-EBx
2.6 2.9 10.5 0.96 2094-BMP5-M
LDAT-S103010-DBx 3.8
8.6
702 (158)
31.5
1935 (435)
2.41
2094-BM02-M
LDAT-S103020-DBx
5.0 2.93
LDAT-S103030-DBx
…
LDAT-S103090-DBx
LDAT-S103010-EBx
…
LDAT-S103090-EBx
1.8 2.9 10.5 0.92 2094-BMP5-M
LDAT-S104010-DBx 4.1
11.5
929 (209)
42.0
2578 (580)
3.76
2094-BM02-M
LDAT-S104020-DBx
5.0 4.29
LDAT-S104030-DBx
…
LDAT-S104090-DBx
LDAT-S104010-EBx
…
LDAT-S104090-EBx
2.7 5.7 21.0 2.07 2094-BM01-M
LDAT-S106010-DBx 4.5
17.3
1403 (315)
63.0
3871 (870)
5.41
2094-BM03-M
LDAT-S106020-DBx
…
LDAT-S106090-DBx
5.0 5.87
LDAT-S106010-EBx
…
LDAT-S106090-EBx
2.7 8.6 31.5 2.94 2094-BM02-M
Performance Specifications (frame 150) with Kinetix 6200/6500 Drives
Linear Thruster
Cat. No.
Velocity, max
460V AC
m/s
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Rated Output 460V
AC
kW
Kinetix 6200/6500
400V-class Drives
LDAT-S152010-DBx 3.2
5.3
643 (145)
19.5
1799 (404)
1.76
2094-BM01-M
LDAT-S152020-DBx
…
LDAT-S152090-DBx
3.5 1.89
LDAT-S152010-EBx
…
LDAT-S152090-EBx
1.8 2.7 9.8 0.87 2094-BMP5-M
LDAT-S153010-DBx
…
LDAT-S153090-DBx
3.6 8.0
978 (220)
29.1
2680 (602)
2.87 2094-BM01-M
LDAT-S153010-EBx
…
LDAT-S153090-EBx
1.2 2.7 9.1 0.80 2094-BMP5-M
