Rockwell Automation Publication KNX-SG001H-EN-P - December 2020 231
Kinetix 300 and Kinetix 350 EtherNet/IP Servo Drives
Performance Specifications with Kinetix 300 (200V-class, three-phase) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient temperature, and rated line
voltage. For additional information on ambient temperature and line conditions, refer to Motion Analyzer.
Linear Motor Cat. No.
Maximum Speed
m/s (ft/s)
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
A 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 300
200V-class
Three-phase Drives
LDL-N030120-DHT
10.0 (32.8)
3.0 63 (14) 9.9 209 (47) 0.31 2097-V33PR3
LDL-N030240-DHT 6.0
126 (28)
19.9
417 (94) 0.63
2097-V33PR5
LDL-N030240-EHT 3.0 9.9 2097-V33PR3
LDL-T030120-DHT 3.0 72 (16) 9.9 239 (54) 0.36 2097-V33PR3
LDL-T030240-DHT 6.0
144 (32)
19.9
479 (108) 0.72
2097-V33PR5
LDL-T030240-EHT 3.0 9.9 2097-V33PR3
LDL-N050120-DHT
10.0 (32.8)
2.7 96 (22) 9.1 317 (71) 0.48 2097-V33PR1
LDL-N050240-DHT 5.5
191 (43)
18.1
635 (143) 0.95
2097-V33PR3
LDL-N050240-EHT 2.7 9.1 2097-V33PR1
LDL-N050360-DHT 8.2
287 (65)
27.2
952 (214) 1.43
2097-V33PR5
LDL-N050360-EHT 2.7 9.1 2097-V33PR1
LDL-N050480-DHT 10.9
383 (86)
36.3
1269 (285) 1.91
2097-V33PR6
LDL-N050480-EHT 5.5 18.1 2097-V33PR3
LDL-T050120-DHT 2.7 110 (25) 9.1 364 (82) 0.55 2097-V33PR1
LDL-T050240-DHT 5.5
220 (49)
18.1
728 (164) 1.10
2097-V33PR3
LDL-T050240-EHT 2.7 9.1 2097-V33PR1
LDL-T050360-DHT 8.2 329 (74) 27.2 1093 (246) 1.64 2097-V33PR5
LDL-T050480-DHT 10.9
439 (99)
36.3
1457 (327) 2.19
2097-V33PR6
LDL-T050480-EHT 5.5 18.1 2097-V33PR3
LDL-N075480-DHT
10.0 (32.8)
9.9
519 (117)
32.8
1723 (387) 2.59
2097-V33PR5
LDL-N075480-EHT 4.9 16.4 2097-V33PR3
LDL-T075480-DHT 9.9
596 (134)
32.8
1977 (444) 2.98
2097-V33PR5
LDL-T075480-EHT 4.9 16.4 2097-V33PR3
