Rockwell Automation Allen-Bradley Kinetix 5500 Installation Instructions

Rockwell Automation Publication 2198-IN001D-EN-P - February 2016 13
Kinetix 5500 Servo Drives
Shared DC (common-bus) Drive Systems
Shared AC Drive Systems
Input Power UL Circuit-protection Specifications
Input Power IEC (non-UL) Circuit-protection Specifications
Kinetix 5500 Drive
Cat. No.
Drive Voltage,
(three-phase)
nom
UL Applications IEC (non-UL) Applications
Bussmann Fuses
Cat. No.
Molded Case CB
Cat. No.
DIN gG Fuses
Amps (max)
Molded Case CB
Cat. No.
2198-H003-ERSx 240/480V KTK-R-10 N/A 10 N/A
2198-H008-ERSx 240/480V KTK-R-10 N/A 10 N/A
2198-H015-ERSx 240/480V KTK-R-15 140U-D6D3-C15 16 140U-D6D3-C15
2198-H025-ERSx 240/480V KTK-R-20 140U-D6D3-C20 20 140U-D6D3-C20
2198-H040-ERSx 240/480V KTK-R-25 140U-D6D3-C25 25 140U-D6D3-C25
2198-H070-ERSx 240/480V LPJ-35SP 140G-G6C3-C40 35 140G-G6C3-C40
Kinetix 5500
Drive Cat. No.
Drive Voltage,
(three-phase)
nom
Bussmann Fuses
Cat. No.
Molded Case CB
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx 240/480V KTK-R-15 N/A
2198-H008-ERSx 240/480V KTK-R-15 N/A
2198-H015-ERSx 240/480V KTK-R-20 KTK-R-25 N/A 140U-D6D3-C15 140U-D6D3-C20 N/A
2198-H025-ERSx 240/480V KTK-R-30 N/A 140U-D6D3-C25 140U-D6D3-C30 N/A
2198-H040-ERSx 240/480V LPJ-35SP LPJ-45SP N/A N/A
2198-H070-ERSx 240/480V LPJ-60SP N/A 140G-G6C3-C60 N/A
Kinetix 5500
Drive Cat. No.
Drive Voltage,
(three-phase)
nom
DIN gG Fuses
Amps (max)
Molded Case CB
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx 240/480V 16 N/A
2198-H008-ERSx 240/480V 16 N/A
2198-H015-ERSx 240/480V 20 25 N/A 140U-D6D3-C15 140U-D6D3-C20 N/A
2198-H025-ERSx 240/480V 32 N/A 140U-D6D3-C25 140U-D6D3-C30 N/A
2198-H040-ERSx 240/480V 35 N/A N/A
2198-H070-ERSx 240/480V 63 N/A 140G-G6C3-C60 N/A
