Publication 2711P-UM001D-EN-P - September 2005
4-10 Configuration Mode
ControlNet Properties
The ControlNet Properties screen configures communication settings
for the terminal on a ControlNet network.
DeviceNet Properties
The DeviceNet Properties screen configures communication settings
for the terminal on a ControlNet network.
Serial Properties
The Serial Properties screen configures settings for serial
communications (using the RS-232 serial port) on the terminal.
Field Description Valid Values
Device ID Unique address of the terminal on the
ControlNet network.
1 - 99
Field Description Valid Values
MacID Unique address of the terminal on the
DeviceNet network.
0 - 63
Baud Rate The baud rate at which the DeviceNet driver
communicates.
125K (default)
250K
500K
Field Description Valid Values
Device The serial device your terminal is connected
to.
PLC_CH0
KF2
SLC_CH0
KF3
KFC
KFC15
AC_CH0
Error Check Type of error checking used. Error checking is
automatically configured if Use Auto Config
is set to Yes.
BCC, CRC
Parity Type of parity used. The parity is
automatically configured if Use Auto Config
is set to Yes.
None, Odd, Even
Stop Bits Number of stop bits used. 1 or 2
Ack Timeout Ack/Poll timeout value in milliseconds. 20 - 60,000 ms
Max Retries Maximum number of retries before the serial
driver fails.
0 - 255
Station Station number based on a specific device. PLC_CH0 0-77 (octal)
KF2 0-77 (octal)
SLC_CH0 0-31
KF3 0-31
KFC 1-99
KFC15 1-99
AC_CH0 0-255
